Product Material | Steel |
Wall to Centre of Tappings | 61-71MM |
Floor To Centre of Tappings | >200 |
Dual Fuel | No |
Element Wattage Compatible | Yes |
Element Wattage | 250 W |
BTU @ 50°C | 877 |
WEEE Certification (Heating) | Yes |
RoHS Certification (Heating) | Yes |
Tube Diameter | 22MM |
Pipe Centres – If Vertical | 450 MM |
Thermal Output @ 50°C (Watts) | 257 |
Type Of Heat | Electrical |
Electrical Connection | Hardwired |
Mount Type | Wall Mounted |
Number Of Heat Settings | 1 |
Number Of Sections/Panels | 10 |
Product Orientation | Vertical |
Brackets Included | Yes |
Assembly Required | No |
Commercial Use | Yes |
Projection | 76/86 |
Installation Required | Yes |
BTU @ 30°C | 471 |
Thermal Output @ 30°C (Watts) | 138 |
BTU @ 60°C | 1095 |
Thermal Output @ 60°C (Watts) | 321 |
IP Rating (Heating) | IP64 Ingress Protection |
