Product Material | Steel |
Wall to Centre of Tappings | 51 |
RAL Number | 7016 |
BTU @ 50°C | 1863 |
Thermal Output @ 50°C (Watts) | 546 |
Type Of Heat | Water |
Mount Type | Wall Mounted |
Number Of Heat Settings | 1 |
Number Of Sections/Panels | 20 |
Product Orientation | Horizontal |
Brackets Included | Yes |
Assembly Required | No |
Commercial Use | No |
Projection | 110MM |
Installation Required | Yes |
BTU @ 30°C | 965 |
Thermal Output @ 30°C (Watts) | 283 |
BTU @ 60°C | 2360 |
Thermal Output @ 60°C (Watts) | 692 |
Pipe Centres – If Horizontal | 676 |
